DESCRIPTION
• Fixed Blade Turbulent Diffuser.
• Adjustable Blade Turbulent Diffuser.

HTD Series Turbulent Diffusers are manufactured as fixed blade or movable blades to cater for winter or summer adjustment. They are used for optimum air distribution using the swirl effect of the air and are recommended for use in premises where the ceiling height is at least 3.5 metres (Shopping Malls, Cinema and Theatres, Sports Halls, Conference Halls etc.). Dependent on choice, they can be manufactured as fixed blade, handle command, or servo motor controlled movable blade models. For turbulence Diffusers with adjustable blades, the blade deflection angles can be adjusted by manually or by use of a servomotor. Only 1st class aluminium profiles are used.


MATERIAL
Product casing is manufactured from 1 mm DKP sheet by spinning method, blades are from galvanized or DKP sheet.

SURFACE COATING
• Electrostatic powder coating (Standard colours are RAL 9010 and RAL 9016)
• As an option all the colours in other RAL codes can be provided

ASSEMBLY
• Installation with screw

ACCESSORIES
• PK: Plenum box
• SM: Servo Motor
